Drolet Escape 1500-I Wood Insert with Trio (35FT) DB03137K3
Product Description
Combining performance and respect for the environment, the Escape 1500 is the perfect choice for heating homes up to 1,800 ft². With only 2.4 g/h of particulate emissions, this non-catalytic wood insert gives off up to 65,000 BTU/h while largely meeting EPA standards. The Escape 1500 is the perfect way to update your masonry fireplace, and make it efficient!
Included: 6" liner kit (35' Vortex flexible stainless steel liner, connector, 13" x 13" top plate, chimney cap with no screen), 29" x 44" faceplate, blower, ceramic glass, ash lip, air damper
- Burn time up to 7 hours
- Up to 18" logs
- Robust 5/16" steel reinforced with a stainless steel heat shield
- EPA certified
- Proudly made in Canada
- Limited lifetime warranty
Any installation must be done according to the data and drawings detailed in the owner’s manual.
Appliance performance
|
Fuel type |
Dry cordwood (16" recommended) |
|
Recommended heating area |
500 - 1,800 ft² |
|
Overall firebox volume |
1.86 ft³ |
|
EPA loading volume |
1.44 ft³ |
|
Maximum burn time |
7 h |
|
Maximum heat output-dry cordwood |
65,000 BTU/h (19 kW) |
|
Minimum overall heat output rate |
9,800 BTU/h (2.87 kW) |
|
Maximum overall heat output rate |
52,200 BTU/h (15.3 kW) |
|
Average overall efficiency-dry cordwood (HHV |
68 % |
|
Average overall efficiency-dry cordwood (LHV |
73 % |
|
Optimum efficiency |
76 % |
|
Optimum heat transfer efficiency |
75 % |
|
Average particulate emission rate |
2.4 g/h |
|
Average CO |
103 g/h |
General Features
|
Premium quality blower included (CFM) |
144 CFM included |
|
Certified according to applicable standards |
By an accredited laboratory (CAN/USA) |
|
Combustion technology |
Non-catalytic |
|
Stainless-steel secondary-air system |
Yes |
|
Flue outlet diameter |
6" |
|
Distance-center of the flue outlet to back unit |
5 3/4" |
|
Distance-center of the flue outlet to side unit |
12 3/4" |
|
Recommended chimney diameter |
6" |
|
Type of chimney |
Liner - ULC-S635, CAN/ULC-S640, UL1777
|
|
Minimum chimney height |
12' |
|
Overall dimension (Width) |
27 1/4" |
|
Overall dimension (Height) |
21 1/4" |
|
Overall dimension (Depth) |
22 3/8" |
|
Door type |
Single, glass with cast iron frame |
|
Door opening size (Width) |
17 1/4" |
|
Door opening size (Height) |
8 3/4" |
|
Glass type |
Ceramic glass |
|
Glass surface - W x H |
15 3/4" x 9 3/4" |
|
Steel thickness-body |
3/16" |
|
Steel thickness-top |
5/16" |
|
Firebox size (Width) |
19 5/8" |
|
Firebox size (Height) |
11 7/8" |
|
Firebox size (Depth) |
13 1/2" |
|
Maximum log length |
18" |
|
Log positioning |
Loading over width |
|
Firebox lined with refractory bricks |
Yes |
|
Baffle type |
High quality vermiculite |
|
Minimum fireplace opening (Width) |
27 1/2" |
|
Minimum fireplace opening (Height) |
21 1/2" |
|
Minimum fireplace opening (Depth) |
12 3/4" |
|
High-efficiency certified appliance |
Yes, EPA 2020 approved |
|
Canadian Standard (emissions) |
CSA B415.1-10 |
|
USA Standard (emissions) |
EPA |
|
Canadian Standard (safety) |
ULC S628 |
|
USA Standard (safety) |
UL 1482, UL 737 |
|
Warranty |
Limited lifetime |
|
Shipping weight |
360 lb (163 kg) |
|
Approved as add-on to an existing furnace |
No |
Clearances
| CLEARANCE | SINGLE WALL PIPE | DOUBLE WALL PIPE |
| Base of the unit to ceiling | 84" |
Product Documents
Wood insert manual | Safety notifications & general information
Installation & Operation Requirements
